CBF84S (354) Main

Specifications

  • Number of Stations 4
  • Imperial Size Reference 3/8"
  • Max Wire Diameter 10 mm
  • Max Cutoff Length 100 mm
  • Max Knockout Length 85 mm
  • P.K.O. Stroke 16 mm
  • Max Forging Tonnage 60 mt
  • Main Motor Power 30 hp
  • Max Speed 200 ppm
  • Weight 14,500 kg

Description

Used 5/16" CBF-84S Progressive Header:

Year: 1996

  • IFO Transfer
  • PKO
  • Bushing Cutoff

Features

  • Standard Hand Tools
  • Standard spare parts
  • Standard "I" type product conveyor
  • Horizontal uncoiler with wire straightener
  • Operator stand
  • AC motor with ABB inverter
  • Shihlin made PLC
  • Pneumatic transfer mechanism with pre-setting block
  • Air clutch
  • Standard cover
  • Motorized adjustable feed length
  • Adjustable K.O. length
  • AC motor with ABB inverter
  • Adjustable stopper length
  • Low air pressure detector
  • Wire end detector
  • Shihlin made PLC
  • Short feed detector
  • Motor overload detector
  • Low oil shutoff
  • Two-hand jogging safety interlock
  • Fluorescent lamp at feeding & K.O. station
  • Punch wedge adjustment with digital display
  • MPG system for slow jogging
  • CE Type emergency stop system
  • Hydraulic transfer block clamping system
  • Temperature detection sensor
  • Cam type blowing device
  • Integrated Trim Station
  • Standard Hand Tools
  • Trimming in Last Station
  • Standard spare parts
  • Standard "I" type product conveyor
  • Horizontal uncoiler with wire straightener
  • Operator Stand
  • Pneumatic transfer mechanism with pre-setting block
  • Air clutch
  • Full protective safety cover
  • Motorized adjustable feed length
  • Adjustable K.O. length
  • Adjustable stopper length
  • Low air pressure detector
  • Wire end detector
  • Short feed detector
  • Motor overload detector
  • Low oil shutoff
  • Two-hand jogging safety interlock
  • Fluorescent lamp at feeding & K.O. station
  • Punch wedge adjustment with digital display
  • MPG system for slow jogging
  • CE Type emergency stop system
  • Hydraulic transfer block clamping system
  • Temperature detection sensor
  • Cam type blowing device
  • Preset holes for process monitor
  • Trimming in Last Station
  • Test Tooling
  • Dual plane wire straightener assembly with cover and safety switch
  • IE3 Electric Motor
  • Mitsubishi PLC
  • CE compliant upgrade package
  • Contactless safety switches with M12 A-CODED Disconnect
  • Electrical cabinet door interlock
  • 20% increase control panel volume
  • Pre-cut holes for exhaust handling
  • Extended exit chute for takeaway conveyor
  • HMI Operation Panel (24V DC)
  • FM series Centrifuge filter
  • "I" Type chip conveyor
  • Automatic Coolant Nozzle Lift
  • LED Three-color Warning Light
  • Punch sleeves included at all stations
  • Branch feeding function
  • Safety door interlock detection
  • Emergency Stop Switches at Panel, Infeed, and Scrap Side
